Zenith Disc Cruiser 24"

The all new Zenith Disc is the most technologically advanced bike that DK has ever assembled. This podium topping pro level racer is built on the 100% custom crafted Zenith frame with patent pending sliding flat mount disc brake system.

Zenith’s share the same proven low-profile geometry as the DK Professional frame providing max speed and stability. Available in six frame sizes including the Zenith Disc 24-inch cruiser. All matched with pro level componentry: BOX X5 carbon fiber forks, DUO Brand drivetrains, and Maxxis rubber. Made to accelerate. Engineered for winning.

NOTE: The DK Zenith Disc frame is compatible with flat mount disc brakes only. Flat mount is more compact and lighter than post mount. With flat mount, the rear caliper affixed with two bolts running through a flattened frame surface and then threading directly into the caliper (or an adapter affixed to the caliper).

Colour: Black (Images differ from colour available)






    SPECIFICATIONS

    Frame
    DK Zenith Disc hydroformed 6061 aluminum frame with tapered head tube, internal cable routing, CNC machined bridges, and forged sliding flat mount disc brake system
    Rims
    DUO Brand R2, double wall, 36-hole, front and rear specific design


    Fork
    BOX X⁵ carbon with 20mm thru-axle
    Front Hub
    DUO Brand R2, fully sealed, 20mm thru-axle


    Handlebar
    6.5" rise, 100% chromoly
    Rear Hub
    DUO Brand R2 Disc, fully sealed, 15mm thru-axle, 16-tooth cassette with 120 engagement points


    Grips
    DK Tsuka lock-on with press-in bar plugs
    Head Tube Angle
    73º


    Stem
    DK forged alloy top load, 50mm reach
    Seat
    BOX Echelon 1-piece seat/post combo


    Headset
    DUO Brand, sealed integrated, tapered
    Seat Post
    Integrated, 27.2mm, alloy


    Cranks
    DUO Brand C2 forged hollow alloy 2-piece, 175mm
    Seat Post Clamp
    Alloy


    BB
    European external (outboard)
    Tyres
    20x1.75” Maxxis DTH


    Pedals
    DUO Brand Resilite platform
    Top Tube Length
    21.75”


    Sprocket
    DUO Brand 40-tooth, CNC machined, alloy, 4-bolt chainring
    Colour
    Destroyer Grey


    Chain
    Taya TB980 3/32”
    RRP
    AU$2,999
